O-LD

Base Product

Available in:
Asia
Australia/New Zealand

Fiber Optic Cable, Outdoor Arid Core Gel-Filled Tubes, Stranded Loose Tube Double Jacket, All Dielectric

Configure Product Variants

Find a Partner

Specifications

Finish making your selections or clear them to view relevant specifications.

Download

Your web browser (Internet Explorer 11 or lower) is out of date and the functions below will not work with Internet Explorer.
Update your browser for more security, speed, functionality and experience on this site.

Update browser

Product Variants Show All Clear

Configure and display product variants of O-LD by selecting options

Product	Jacket Marking	Regional Availability	Portfolio	Product Series	Product Type	Cable Type	Construction Type	Jacket Color	Total Fiber Count	Jacket Material	Fiber Type	Environmental Space	Subunit Type
64623447-06MLT \| O-006-LD-8M-M06BL/15G/PE/PA 6 Core OS2 Outdoor Mini Loose Tube - Double Jacket Specifications	Meters	Asia \| Australia/New Zealand	CommScope®	O-LN	Fiber OSP cable	Stranded loose tube	Non-armored	Blue	6	Nylon \| PE	G.652.D	Buried \| Underground (duct)	Gel-filled
64623447-12MLT \| O-012-LN-8M-M12BL 12 Core OS2 Outdoor Mini Loose Tube - Double Jacket Specifications	Meters	Asia \| Australia/New Zealand	CommScope®	O-LN	Fiber OSP cable	Stranded loose tube	Non-armored	Blue	12	Nylon \| PE	G.652.D	Buried \| Underground (duct)	Gel-filled
64623447-24MLT \| O-024-LN-8M-M12BL 24 Core OS2 Outdoor Mini Loose Tube - Double Jacket Specifications	Meters	Asia \| Australia/New Zealand	CommScope®	O-LN	Fiber OSP cable	Stranded loose tube	Non-armored	Blue	24	Nylon \| PE	G.652.D	Buried \| Underground (duct)	Gel-filled
64623447-288MLT \| O-288-LD-8M-M24BL/17G/PE/PA 288 Core OS2 Outdoor Mini Loose Tube - Double Jacket Specifications	Meters	Asia \| Australia/New Zealand	CommScope®	O-LN	Fiber OSP cable	Stranded loose tube	Non-armored	Black	288	Nylon \| PE	G.652.D	Buried \| Underground (duct)	Gel-filled
64623447-48MLT \| O-048-LD-8M-M12BL/15G/PE/PA 48 Core OS2 Outdoor Mini Loose Tube - Double Jacket Specifications	Meters	Asia \| Australia/New Zealand	CommScope®	O-LN	Fiber OSP cable	Stranded loose tube	Non-armored	Blue	48	Nylon \| PE	G.652.D	Buried \| Underground (duct)	Gel-filled
64623447-96MLT \| O-096-LD-8M-M12BL/15G/PE/PA 96 Core OS2 Outdoor Mini Loose Tube - Double Jacket Specifications	Meters	Asia \| Australia/New Zealand	CommScope®	O-LN	Fiber OSP cable	Stranded loose tube	Non-armored	Blue	96	Nylon \| PE	G.652.D	Buried \| Underground (duct)	Gel-filled
64624447-06 \| O-006-LD-8M-M12BL/20G/PE/PA Outdoor Fiber Cable, 6-fiber, singlemode OS2, loose tube, blue Specifications	Meters	Australia/New Zealand	CommScope®	O-LD	Fiber OSP cable	Loose tube		Blue	6	Nylon	G.652.D \| OS2	Buried	Gel-filled
64624447-12 \| O-012-LD-8M-M12BL/20G/PE/PA Outdoor Fiber Cable, 12-fiber, singlemode OS2, loose tube, blue Specifications	Meters	Australia/New Zealand	CommScope®	O-LD	Fiber OSP cable	Loose tube		Blue	12	Nylon	G.652.D \| OS2	Buried	Gel-filled

Features and Benefits

CommScope’s outside plant fiber cables are made with high-performance, standards-compliant materials
The portfolio includes both armored and dielectric designs available with dry or gel-filled tubes
Superior mechanical and optical performance with unmatched stability and quality

Specifications
