760220400 | 360CM12-2x3-TS

Base Product: G2-MODULES

  • Available in:
  • Asia
  • Australia/New Zealand
  • EMEA
  • Latin America
  • North America

G2 2x3 Singlemode Conversion Module, 3 MPO male ports

Find a Partner
Specifications
Finish making your selections or clear them to view relevant specifications.
Download

Product classification

Regional Availability Asia | Australia/New Zealand | EMEA | Latin America | North America
Portfolio CommScope®
Product Type Fiber module

General Specifications

Functionality Breakout
Adapters, quantity, front 3
Adapters, quantity, rear 2
Color, front Blue
Color, housing Black
Color, rear Blue
Data Module Type Standard
Interface, front MPO
Interface Feature, front Standard
Interface, rear MPO
Interface Feature, rear Male | Reduced footprint
Polarity Method B Enhanced (ULL)
Shuttered No
Total Fibers, quantity 24
Total Ports, quantity, front 3

Dimensions

Height 27.94 mm | 1.1 in
Width 91.44 mm | 3.6 in
Depth 109.22 mm | 4.3 in

Optical Specifications

Fiber Mode Singlemode
Fiber Type G.652.D and G.657.A1, TeraSPEED® | OS2
Insertion Loss Change, mating 0.3 dB
Insertion Loss Change, temperature 0.3 dB
Insertion Loss, maximum 1.34 dB

Environmental Specifications

Safety Standard UL

Packaging and Weights

Packaging quantity 1

Regulatory Compliance/Certifications

Agency Classification
CHINA-ROHS Below maximum concentration value
ISO 9001:2015 Designed, manufactured and/or distributed under this quality management system
REACH-SVHC Compliant as per SVHC revision on www.commscope.com/ProductCompliance
ROHS Compliant
UK-ROHS Compliant, Compliant/Exempted
