760259800 | IFEB-40TPL2096-C24S-GJJNN

Base Product: IFEB

Available in:
EMEA

IFEB40, Indoor Fiber Optic Wall mount Enclosure, Splice / Patch, LC/APC Pigtails and Adapters (96),Single Elemet Slim trays(24) Smouv, Feeder Cable Seal 4x15mm and 24x7mm drop seal(2), RAL 9010

Find a Partner

Specifications

Finish making your selections or clear them to view relevant specifications.

Download

Features and Benefits

Compact, wall mountable fiber enclosures for indoor use
Specifically designed for fast FTTH deployment and easy customer connection
Configurable as splice only or connectorized solution
Multiple and modular wrap around cable port sealing options to suit a wide range of cables
Easy intergration of 900μm connectorised or 250μm splice splitters (inactive)
Single Element (SE), Single Slim Element (SLE) or Single Circuit (SC) tray options - Smouv and ANT
Powered by NOVUX™

Specifications

Product classification

Regional Availability	EMEA
Portfolio	CommScope®
Product Type	Fiber wall box
Product Series	IFEB-40

General Specifications

Functionality	Patching \| Splicing
Access	Front
Adapter Ports, quantity	96
Cable Ports, quantity	4
Drop Port, quantity	48
Enclosure Color	Pure White (RAL 9010)
Front Cover Type	Snap-on cover
Interface	LC/APC
Pigtails Included, quantity	96
Splice Tray Construction	SLE (Slim element tray for up to 12 primary coated fibers)
Splicing Capacity, maximum	288
Splicing Type	SMOUV

Dimensions

Height	425 mm \| 16.732 in
Height, with cover	500 mm \| 19.685 in
Width	295 mm \| 11.614 in
Depth	145 mm \| 5.709 in
Volume	14.1 L

Dimension Drawing

Click on image to enlarge.

Environmental Specifications

Installation temperature	-5 °C to +45 °C (+23 °F to +113 °F)
Operating Temperature	-10 °C to +60 °C (+14 °F to +140 °F)
Environmental Space	Indoor
Flammability Rating	UL 94 V-0
Qualification Standards	IEC 60529, IP50 \| IEC 61753-1 Ed.2 2018 - Category C

Packaging and Weights

Included	Adapters (24) \| Box (1) \| Drop Seal, 24x7 (2) \| Feeder Seal, 4x15 (1) \| SLE Smouv trays (24)
Packaging quantity	1
Packaging Type	Box

Regulatory Compliance/Certifications

Agency	Classification
CHINA-ROHS	Above maximum concentration value
ROHS	Compliant/Exempted
UK-ROHS	Compliant/Exempted
