Etisalat UAE Utilizes CommScope Low Loss Combiners

Paolo di Carne--thumbnail Paolo Di Carne December 15, 2015
UAE--compressedThe Middle East—Africa region is among the fastest-growing wireless markets in the world. But with explosive growth comes significant challenges including overloaded towers and rooftops, and few available options for new sites. With minimal insertion loss compared to traditional hybrid units, CommScope’s customized low-loss combiners are enabling Etisalat UAE to expand their network on existing sites—without a major CapEx investment.

To meet the increased capacity demanded by higher data throughput in the country, Etisalat UAE has been forced to add new antennas at existing sites on rooftops or towers for UMTS 900 MHz or LTE 1800 MHz bands. Most of the time, they are facing situations where rooftops are already full of antennas—or towers are already overloaded, with serious stability and wind-load issues.

One solution is a same-band combiner—a unit that combines two base stations on the same band (GSM900 and UMTS900) into a common port to reduce the number of antennas required. But introducing a passive unit in the RF path usually leads to an insertion loss that reduces the power available for coverage and capacity.

To minimize this power loss, CommScope has developed a new type of in-band combiner designed to deliver only 0.5 dB of insertion loss—compared with traditional one-size-fits-all hybrid combiners that lose 3 dB and essentially waste most of the power available. CommScope’s low loss combiners are custom solutions tailored to the client’s spectrum, which enable carriers to reduce the number of antennas and speed up network expansion. After successful trials performed at outdoor and indoor sites, Etisalat UAE decided to adopt the low loss combiner UMTS900 solution to upgrade their network sites.

To learn more about low loss combiners and the Etisalat project see the full text of our recent success story, CommScope low-loss combiners deliver network modernization solutions to UAE’s top wireless carrier.

Do you have any questionsabout these innovative products? Do not hesitate to leave a comment, and I’ll happily reply.

About the Author

Paolo di Carne--thumbnail

Paolo Di Carne

Paolo di Carne is applications engineering manager for the Middle East and Africa at CommScope, responsible for enhancing the company’s technical leadership position with filter and tower mounted amplifier products. Paolo has nearly 20 years’ experience in the telecommunications sector, including nine years in a technical department and five years in a sales department, covering different positions and tasks like presales manager, service delivery manager and project manager. He has worked as an RF engineer and in other roles at AdvaComm, Ericsson, Devoteam, Nokia Siemens Networks, and Telecom Italia. Paolo has a degree in electronic engineering from the Politecnico di Milano, where he wrote a graduate thesis about GSM/UMTS mobile communication networks.
