“Our antenna/RRU SiteRise Standard Interface combines the best features of putting remote radios close to the antenna for reducing signal loss and energy consumption, but maintains a level of independence between the radio and antenna for flexibility and ease of support”
Expanding on its award winning Andrew SiteRise solution, CommScope is introducing a new innovation aimed at reducing
installation and maintenance cost, risk and time at the top of cellular network
towers. The Andrew® SiteRise™ Standard
Interface is intended to simplify the interface between the base station
antenna and virtually any remote radio unit (RRU) technology.
Andrew SiteRise, unveiled in 2013, is the world’s first pre-assembled tower top solution, designed to
bring factory assembled quality and consistency to the field assembly
environment of a wireless network cell site. Andrew SiteRise facilitates the
rapid implementation of RRU technology in close physical proximity to the
antenna connectors, reducing losses and improving network performance. The
SiteRise solution already is proving cost-effective for operators by moving the
complex connection, configuration and testing work from the top of the tower to
ground level where it can be done in a controlled environment.
“Since we began implementing the SiteRise solution in close
collaboration with a major wireless operator, we have continued to work closely
with the whole operator community to understand what innovations would be of
additional value to them,” said Ben Cardwell, senior vice president, Global
Wireless Sales, CommScope. “Those conversations led to a new SiteRise solution
aimed at even greater simplification of the radio and antenna interface, which
provides for even less interference risk, better flexibility and a true
plug-and-play capability at the top of the tower.”
SiteRise Standard Interface is a new way of connecting an RRU to the
base station antenna, using a unique approach not previously utilized for tower
top applications. SiteRise Standard Interface gives an operator the flexibility
of using multiple RRU technologies and frequency bands in a simplified
plug-and-play arrangement. Key to this solution is a patented connector technology
that provides an essentially passive intermodulation (PIM)-free, blind mate connection.
SiteRise Standard Interface offers lower risk and higher quality
assurance by moving the complex connecting work at the top of the tower into a
more controlled environment. This innovation reduces the risk of craft related
errors due to the harsher and more complex working conditions at the top of the
tower. The easy accessibility enabled by SiteRise Standard Interface makes
upgrading RRUs for changing frequency and technology requirements a
plug-and-play feature. Ultimately, SiteRise Standard Interface reduces the time
installers spend working on the tower, saving operating costs and creating
faster site turn ups, critical for operators’ time-to-market competitive
“Our antenna/RRU SiteRise Standard Interface combines the best features
of putting remote radios close to the antenna for reducing signal loss and
energy consumption, but maintains a level of independence between the radio and
antenna for flexibility and ease of support,” said Cardwell.
SiteRise Standard Interface introduces a new connector technology that
provides an essentially PIM-free, blind mate connection. PIM is a major concern
with today’s interference limited technologies such as LTE. With blind mate
connection capability, upgrading and maintaining radio technology can be done
without affecting the antenna’s position. This functionality reduces the time
and cost associated with radio maintenance, and, even more importantly, reduces
the risks associated with technology obsolescence.
Combining multiple frequencies is also common in today’s cell sites.
SiteRise Standard Interface includes an optional filter integration that
reduces potential sources of interference and the need for more complex
solutions internal to the RRU technology.
As part of its evolution of solutions at the top of the tower, CommScope
is also introducing new approaches for fiber cable connectivity and protection.
Available now, the HELIAX® FiberFeed® Direct cabling solution can enable quicker installations by mating
hybrid fiber and power cable to any RRU model, reducing the number of overall
connections and cutting installation time by half. Complementing CommScope’s HELIAX line of RF cable assembly solutions, the new HELIAX SureGuard™ weather protection system is a simple, easy
to install solution that can weather proof up to 10 antenna connectors in
minutes while requiring no special tooling and being reusable.
of the tower is a difficult place to work, so having a solution that provides
for a more consistent and predictable quality result and provides flexibility
for change just makes sense,” said Morgan Kurk, senior vice president,
Wireless, CommScope. “We are ready to work with all major radio and antenna
OEMs to make this technology broadly available to the benefit of networks
The latest evolution of CommScope’s Andrew SiteRise solution will be
introduced at Mobile World Congress, February 24–27 in Barcelona, Spain. CommScope will be located in
stands 2I46 and 6I06.
