31768A-M

Angle Adapter, standard, M10 tapped hole
Specifications
Finish making your selections or clear them to view relevant specifications.
How to Buy
Specifications

Product Classification

Product Type Adapter
Ordering Note CommScope® non-standard product

General Specifications

Adapter Type Angle adapter
Mounting M10 tapped hole

Dimensions

Inside Width 0.88 in | 22.352 mm
Outside Width 1.96 in | 49.784 mm
Inside Length 0.88 in | 22.352 mm
Outside Length 1.77 in | 44.958 mm
Material Thickness 0.165 in | 4.191 mm

Material Specifications

Material Type Stainless steel

Mechanical Specifications

Installation Torque, maximum 15 ft lb | 20.337 N-m
Installation Torque, minimum 11 ft lb | 14.914 N-m
Maximum Loading Triple stack, 1-5/8 in cable

Packaging and Weights

Height, packed 14.2 cm | 5.591 in
Width, packed 14.2 cm | 5.591 in
Length, packed 10.2 cm | 4.016 in
Packaging quantity 10
Weight, gross 2.33 kg | 5.137 lb

Regulatory Compliance/Certifications

Agency Classification
ISO 9001:2015 ISO 9001:2015Designed, manufactured and/or distributed under this quality management system
