Single Support Arm, 48 in, includes pipe
| Product Type | Universal ring mount |
| Mounting | Ring mount |
| Pipe, quantity | 1 |
| Height | 457.2 mm | 18 in |
| Width | 254 mm | 10 in |
| Length | 1219.2 mm | 48 in |
| Pipe Length | 457.2 mm | 18 in |
| Pipe Outer Diameter | 114.3 mm | 4.5 in |
| Stand-off Distance | 1219.2 mm | 48 in |
| Click on image to enlarge. |
| Material Type | Hot dip galvanized steel |
| Wind Rating | 120 mph (BWS) at 150 ft AGL | 140 mph (3-second gust) at 150 ft AGL using Exposure D per FBC |
| Wind Rating Criteria | Four 72 in x 8 in panel antennas per sector |
| Wind Rating Test Method | TIA/EIA-222 |
| Man Rating | 250 lb vertical man load at 15 mph (BWS) |
| Included | Hardware | Stand-off arms |
| Packaging quantity | 1 |
| Weight, net | 37.2 kg | 82.012 lb |
| Agency | Classification |
ISO 9001:2015
|
Designed, manufactured and/or distributed under this quality management system |
